MASW & VS30 Shear Wave Velocity Testing in Barrie

The 24-channel Geometrics Geode seismograph deploys in a linear array across Barrie job sites, its 4.5 Hz geophones spiked into the pavement or grassed lots of the city’s south-end developments. A 10 kg sledgehammer strikes an aluminum plate at the first offset, and the dispersive wave train rolls through the receiver spread—Rayleigh waves that sample progressively deeper as frequency drops. The raw record shows fundamental-mode energy from 30 Hz down to about 4 Hz on a typical 46 m spread over the Simcoe till, giving a velocity profile reaching 30 m depth without a borehole. In the soft clay pockets around Kempenfelt Bay, the array extends to 69 m to push the investigation depth past 40 m, capturing the contact with the limestone bedrock that underlies much of the city’s waterfront. For sites with background traffic noise from Highway 400, the seismic refraction survey can be run on the same geophone line to extract P-wave velocities and cross-check the shallow layering, while the liquefaction assessment uses the resulting Vs profile to evaluate triggering potential in the saturated sands near the lake shore.

A single MASW line can replace three boreholes for Vs30 determination when the stratigraphy is laterally uniform, cutting site characterization time in half.

Process overview

The NBCC 2020 seismic provisions rely on the time-averaged shear wave velocity in the upper 30 m (Vs30) to assign Site Class—and in Barrie, that classification can shift a full letter depending on whether the till is dense or interbedded with softer glaciolacustrine clay. The MASW method satisfies ASTM D4428 / D7400 for surface wave testing, and the dispersion curve inversion is performed iteratively with initial model constraints taken from available well logs or nearby boreholes. Active-source shots at 2 m, 4 m, 8 m, and 16 m offsets stack into each record, while passive recordings of microtremor and vehicle-induced noise extend the dispersion curve below 10 Hz. The fundamental-mode picking follows the phase velocity maximum on the f-k spectrum, and the inversion uses a damped least-squares algorithm with a layered earth model. When the site is underlain by the Simcoe till—a dense, silty diamict with occasional boulders—the Vs30 often lands between 360 m/s and 550 m/s, placing it in Site Class C or D depending on the clay interbeds. A combined test campaign that includes SPT drilling at select locations provides the ground-truth blow counts and lithology to calibrate the velocity boundaries and confirm refusal depth on the bedrock surface.

MASW & VS30 Shear Wave Velocity Testing in Barrie

Local context

Barrie’s development arc from a War of 1812 supply depot to a modern GTA commuter hub has pushed subdivisions onto terrain that the original townsite never touched—glaciolacustrine plains and drumlinized till that behave very differently under seismic loading. The Kempenfelt Bay shoreline, in particular, exposes a succession of soft, normally consolidated silty clays deposited in glacial Lake Algonquin; these clays can produce Vs30 values below 200 m/s, triggering Site Class E assignment and a factor-of-two increase in design spectral accelerations under NBCC 2020 compared to the Class C sites on the till uplands. Missing that classification means the structural engineer designs for the wrong seismic hazard level—potentially undersizing lateral-force-resisting elements or, conversely, over-conserving a foundation that didn’t need the premium. The MASW line also picks up lateral velocity contrasts that hint at buried channels or basin-edge effects; a site near Little Lake can show a 40% Vs reduction over 50 m of lateral offset, a detail that a single borehole log would never reveal.

Need a geotechnical assessment?

Reply within 24h.

Email: contact@geotechnicalengineering.co

Relevant standards

ASTM D4428 / D7400 – Surface wave methods, NBCC 2020 – Site classification based on Vs30, NEHRP (BSSC 2020) – Site class definitions, CSA A23.3 – Concrete structures seismic design (referencing site class)

Additional services

Active-Source MASW

Standard 24-channel acquisition with sledgehammer source and multiple offset positions. Suitable for Vs30 determination on sites with shallow bedrock or dense till, typically reaching 30–35 m depth with a 46 m spread.

Passive & Combined Active/Passive MASW

Longer arrays (up to 69 m) with passive microtremor recording to extend the dispersion curve below 5 Hz. Required for the soft clay sites near Kempenfelt Bay where bedrock lies deeper than 30 m and low-frequency energy is essential.

Vs30 Reporting & NBCC Site Classification

Dispersion curve picking, inversion with layered earth model, and Vs30 calculation. Final report assigns NEHRP / NBCC 2020 Site Class (C, D, or E) with the supporting velocity profile plot and dispersion image.

Typical parameters

Parameter	Typical value
Equipment	Geometrics Geode 24-channel, 4.5 Hz vertical geophones
Source	10 kg sledge on aluminum plate; passive ambient noise
Array configuration	Linear 24-geophone, 2 m spacing typical; extended to 69 m for deep targets
Frequency range acquired	4–30 Hz active; 1–10 Hz passive (microtremor)
Depth of investigation	30–40 m standard; >40 m with extended array over soft clay
Vs30 classification range	Typically 280–600 m/s across Barrie; Site Class C, D, or E
Standard	ASTM D4428, D7400; NBCC 2020 seismic provisions
Output	1D Vs profile, Vs30 value, dispersion image, NEHRP site class

Top questions

How much does a MASW survey cost in Barrie?

The cost for a MASW survey in Barrie typically falls between CA$2,340 and CA$4,070. The final figure depends on the array length needed (46 m versus 69 m extended spread), whether passive data acquisition is added, and the number of lines required for the site. A single active-source line on a standard residential lot sits at the lower end; a combined active/passive campaign with multiple lines for a commercial development near the bay runs toward the upper end.

What site class does the Simcoe till typically produce in Barrie?

The Simcoe till in Barrie generally yields Vs30 values between 360 m/s and 550 m/s, which places it in NBCC Site Class C (very dense soil, 360–760 m/s) or the upper end of Site Class D (stiff soil, 180–360 m/s). The classification can drop to D or even E where softer glaciolacustrine clay layers are interbedded within the till sequence, particularly in the low-lying areas south and east of Kempenfelt Bay.

Can MASW replace boreholes for seismic site classification?

Under NBCC 2020, MASW alone can determine Vs30 and assign the site class when the stratigraphy is reasonably uniform and the dispersion curve is clearly interpretable. In Barrie’s more complex zones—where clay, till, and bedrock alternate over short distances—we typically recommend pairing at least one borehole with SPT testing to calibrate the velocity boundaries and confirm the depth to bedrock. This hybrid approach satisfies both the geotechnical and geophysical requirements without over-instrumenting the site.
